1. The operation is designed according to the principle of ergonomics, which makes the operation more comfortable;
2. The intake, exhaust and cooling systems are optimized to effectively extend the service life of the engine and improve the reliability of the whole machine;
3. It has a reliable power system and adopts a reliable speed change system, which greatly reduces the failure of the whole machine. At the same time, multiple power auxiliary devices effectively guarantee the working reliability of the system;
auxiliary devices effectively guarantee the working reliability of the system;
4. The new steering wheel adjustment mechanism is adopted to improve the comfort of operation and the reliability of adjustment;
5. Reliable LCD digital special instrument and friendly human-machine interface make it easy for the driver to accurately control the vehicle status;
6. The drum brake and full hydraulic power brake make the operation easier, more comfortable and reliable.
| YG-70 Diesel forklift | |
|---|---|
| Machine weight | 9600KG |
| Lifting weight | 7000KG |
| Fork size | 1220*150*65 |
| Load center distance | 600mm |
| Machine size | 3680*1970*2500mm（without fork） |
| Wheelbase | 2250mm |
| Minimum ground clearance | 230mm |
| Mast tilt angle (front/rear) radius | 6°/12° |
| Maximum working speed | 29Km/h |
| Engine model | Quanchai4J1-115C32 |
